Single Path Turntable for Truck & Trailer
RM No.: ZPUA001S – ZPUA015S
Single Path
- Description
Product Description
Single Path U type
RM# | Description | ||||
A (mm) | B(mm) | C(mm) | D(mm) | Load(Ton) | |
ZPUA001S | 1300 | 1308 | 90 | 1146 | 16 |
ZPUA002S | 1200 | 1215 | 90 | 1044 | 14 |
ZPUA003S | 1195 | 1208 | 90 | 1059 | 14 |
ZPUA004S | 1195 | 1208 | 94 | 1046 | 14 |
ZPUA005S | 1100 | 1115 | 90 | 945 | 12 |
ZPUA006S | 1102 | 1110 | 90 | 945 | 12 |
ZPUA007S | 1100 | 1108 | 90 | 945 | 12 |
ZPUA008S | 1013 | 1022 | 84 | 856 | 12 |
ZPUA009S | 1000 | 1015 | 90 | 860 | 8 |
ZPUA010S | 1090 | 1105 | 80 | 966 | 6.5 |
ZPUA011S | 1000 | 1010 | 90 | 856 | 10 |
ZPUA012S | 1000 | 1008 | 90 | 859 | 10 |
ZPUA013S | 1000 | 1015 | 80 | 866 | 6 |
ZPUA014S | 880 | 895 | 80 | 754 | 5 |
ZPUA015S | 685 | 700 | 75 | 563 | 4 |
